New Energy Field
Application Cases

High-efficiency direct-drive motor systems optimize energy conversion efficiency, meeting the high-precision requirements of the entire lithium-ion battery manufacturing process.

Lithium Battery Stacking Equipment Platform

Primarily used for precisely stacking anode/cathode plates with separators to form cell cores, with performance directly determining battery: Energy density、Safety、Service life.

Load: 20kg

Max acc: 2.5G

Repeatability: ± 0.005mm

Max vel: 2.5m/s

Positioning Accuracy: ± 0.01mm

Z-Folding Stacking Equipment Platform

Designed for pouch cell flexible encapsulation, utilizing: Alternating Z-fold separator placement，Synchronized robotic electrode layering.To ensure: Flat electrode- separator interfaces, Elimination of bending defects, Unlike winding processes.

Load: 3kg

Max acc: 2.5G

Repeatability: ± 0.003mm

Max vel: 2.5m/s

Positioning Accuracy: ± 0.005mm

Lithium Battery Assembly Equipment Platform

Engineered for core cell handling, stacking, and welding processes, delivering:Positioning accuracy ≤ 0.1mm, ensuring cell alignment, Non-destructive tab connections, Cold joint rate reduction to <0.1%

Load: 600kg

Max acc: 2G

Repeatability: ± 0.005mm

Max vel: 2m/s

Positioning Accuracy: ± 0.01mm

A matrix of hundreds of standard products, fully adaptable to diverse fields such as electronics, semiconductors, new energy, and consumer electronics.

CHOOSE THE RIGHT PRODUCT FOR YOU

Driven by a top European R&D team, innovating high-precision and high-speed transmission technology.

TMR68 Torque Motor Series

DDE170

LMU15-52-03

LMT23-40-03

LMD25 Cylindrical Linear Motor Series

TC-SSLM150 Series

TC-SLM80-D01-T2306-XXXL

TC-KLM60 Series

TC-DLM160 Series

LMVA135
